BUCK
BUCK circuit is a kind of DC-DC converter based on the principle of inductive energy storage, which involves the basic principles of electromagnetic induction and electric energy conversion in physics. In BUCK circuit, the DC voltage provided by the input power supply is converted to the adjustable low voltage output by controlling the on-on and off-state of the PWM wave switching tube with variable input duty ratio, so as to meet the power supply requirements of different circuits.
MST8815AXKP：80V/3A asynchronous buck DC-DC converter
The MST8815AXKP is a high voltage, Asynchronous step-down converter operates over a wide range input voltage 9V to 80V. The MST8815AXKP integrates a 100-V 400-mΩ high-side MOSFET.
The MST8815AXKP delivers 1.5A continuous load current with up to 95% efficiency. The MST8815AXKP operates with fixed frequency peak current control with built-in compensation eliminates the need for external components.
Cycle-by-cycle current limit in high-side MOSFET protects the converter in an overload condition. Hiccup mode protection is triggered if the over-current condition has persisted for longer than the present time.
The MST8815AXKP exhibits protection features that protect the load from faults like under voltage, over-current and over-temperature.
The MST8815AXKP is available in an ESOP-8 package.
MST8820AXKP：80V/4A asynchronous buck DC-DC converter
The MST8820AXKP is a high voltage, Asynchronous step-down converter operates over a wide range input voltage 9V to 80V. The MST8820AXKP integrates a 100-V 400-mΩ high-side MOSFET.
The MST8820AXKP delivers 2A continuous load current with up to 93% efficiency. The MST8820AXKP operates with fixed frequency peak current control with built-in compensation eliminates the need for external components.
Cycle-by-cycle current limit in high-side MOSFET protects the converter in an overload condition. Hiccup mode protection is triggered if the over-current condition has persisted for longer than the present time.
The MST8820AXKP exhibits protection features that protect the load from faults like under voltage, over-current and over-temperature.
The MST8820AXKP is available in an ESOP-8 package.
MST8A10AXKP：100V/1.5A asynchronous buck DC-DC converter
The MST8A10AXKP is a high voltage, a synchronous step-down converter operates over a wide range input voltage 9V to 100V.
The MST8A10AXKP integrates a 100V 400mΩ high side MOSFET.
The MST8A10AXKP operates with fixed frequency peak current control with built-in compensation eliminates the need for external components.
Cycle-by-cycle current limit in high-side MOSFET protects the converter in an overload condition. Hiccup mode protection is triggered if the over-current condition has persisted for longer than the present time.
The MST8A10AXKP exhibits protection features that protect the load from faults like under voltage,over current and over temperature.
The MST8A10AXKP is available in an ESOP-8 package.
MST8A30AXKP：100V/3A asynchronous buck DC-DC converter
The MST8A30AXKP is a high voltage, asynchronous-stepdown controller operates over a wide range input voltage 9V to 100V. The MST8A30AXKP deliver 3A continuous load current with up to 96% efficiency. The MST8A30AXKP operate with fixed frequency peak current control with built-in compensation eliminates the need for external components. Cycle-by-cycle current limit in high-side MOSFET protects the converter in an overload condition.Hiccup mode protection is trigger if the over-current condition has persisted for longer than the present time.
MST8A30AXKP exhibits protection features that protect the load from faults like under-voltage, over-current and over-temperature.
The MST8A30AXKP is available in an ESOP-8.
MST8A50QA：100V/5A synchronous buck DC-DC converter
The MST8A50QA is a high voltage, synchronous step-down controller operates over a wide range input voltage 9V to 100V. The MST8A50QA delivers 5A continuous load current with up to 96% efficiency.
The MST8A50QA operates with fixed frequency peak current control with built-in compensation eliminates the need for external components. Cycle-by-cycle current limit in high-side MOSFET protects the converter in an overload condition. Hiccup mode protection is triggered if the over-current condition has persisted for longer than the present time.
The MST8A50QA exhibits protection features that protect the load from faults like under-voltage,over-current and over-temperature.
The MST8A50QA is available in an QFN-20(5mm*5mm).
MST8A50Q7：100V/5A synchronous buck DC-DC converter
The MST8A50Q7 is a high voltage, synchronous step-down controller operates over a wide range input voltage 9V to 100V. The MST8A50Q7 delivers 5A continuous load current with up to 96% efficiency.
The MST8A50Q7 operates with fixed frequency peak current control with built-in compensation eliminates the need for external components. Cycle-by-cycle current limit in high-side MOSFET protects the converter in an overload condition. Hiccup mode protection is triggered if the over-current condition has persisted for longer than the present time. The MST8A50Q7 exhibits protection features that protect the load from faults like under-voltage, under-voltage,over-current and over-temperature.
The MST8A50Q7 is available in an QFN-20(7mm*7mm).
MST8A100KE：100V/10A synchronous buck DC-DC converter
The MST8A100KE is a high voltage, synchronous step-down controller operates over a wide range input voltage 9V to 100V. The MST8A100KE delivers 10A continuous load current with up to 96% efficiency.
The MST8A100KE operates with fixed frequency peak current control with built-in compensation eliminates the need for external components. Cycle-by-cycle current limit in high-side MOSFET protects the converter in an overload condition. Hiccup mode protection is triggered if the over-current condition has persisted for longer than the present time.
The MST8A100KE is available in an MSOP-10.
MST8650QA：60V/5A synchronous buck DC-DC converter
The MST8650QA is a high voltage, synchronous step-down controller operates over a wide range input voltage 9V to 60V. The MST8650QA delivers 5A continuous load current with up to 96% efficiency.
The MST8650QA operates with fixed frequency peak current control with built-in compensation eliminates the need for external components. Cycle-by-cycle current limit in high-side MOSFET protects the converter in an overload condition. Hiccup mode protection is triggered if the over-current condition has persisted for longer than the present time.
The MST8650QA exhibits protection features that protect the load from faults like under-voltage,over-current and over-temperature.
The MST8650QA is available in an QFN-20(5mm*5mm).
